NTR Series
Regulated High Voltage Power Supply For Neutron Generator Tubes
General Description
NTR-100 Series high voltage power supplies are designed to power D-T reaction neutron generating tubes used in down-hole environments. They are intended for use in rugged shock and vibration environments and can operate at ambient temperatures up to 175 degrees Celsius.
Using a state of the art parallel multiplier* configuration the NTR series offers efficiencies of up to 50% with low stored energy and are not easily damaged by arcing. The parallel multiplier configuration provides for greater dynamic load regulation than Cockroft-Walton designs while providing ripple typically less than 2% at full power
and the voltage. The output voltage of the NT power supply is easily programmable via analog signals. Both current and voltage monitors are provided.
*patents: 8,085,561, 8,203,858, 8,976,552
Features
Output regulated to +/- 1%
Output voltage programmable
Encapsulated
Vin = 48V (other voltages available)
10 Watt power
175 °Celsius operation (185ºC case)
Internal Sensistor for temperature measurement.
