9113B   Series

25 mm

red/infra-red trialkali

3 x 10⁵

-80 to +60 °C

Red sensitive variant of 9111B, compact, fast response time.
  Length: 43 mm

9130/100B   Series

30 mm

red/infra-red trialkali

1.3 x 10⁶

-80 to +60 °C

Photon counting PMT, 2.5 mm effective diameter, very low   afterpulse rate.
  Length: 112 mm

9130/350B   Series

30 mm

red/infra-red trialkali

1.3 x 10⁶

-80 to +60 °C

Photon counting PMT, 9 mm effective diameter, very low   afterpulse rate.
  Length: 112 mm

9136B   Series

30 mm

red/infra-red trialkali

1 x 10⁶

-80 to +60 °C

Red sensitive variant of 9107B, length 87 mm.
  Length: 87 mm

9828B   Series

30 mm

red/infra-red trialkali

9 x 10⁵

-80 to +60 °C

Variant of 9798B, prismatic window giving enhanced red and IR   sensitivity.
  Length: 112 mm

9670B   Series

30 mm

red/infra-red trialkali

2 x 10⁴

-80 to +60 °C

Position sensitive type.
  Length: 120 mm

9798B   Series

30 mm

red/infra-red trialkali

1.2 x 10⁶

-80 to +60 °C

Red sensitive variant of 9924B.
  Length: 112 mm

9972B   Series

38 mm

red/infra-red trialkali

1 x 10⁵

-80 to +60 °C

Red sensitive variant of 9902B, high gain, fast response and   good linearity.
  Length: 85 mm

9201B   Series

51 mm

red/infra-red trialkali

1 x 10⁶

-80 to +60 °C

Variant of 9266B.
  Length: 100 mm

9202B   Series

51 mm

red/infra-red trialkali

8 x 10⁵

-80 to +60 °C

Fast, pin compatible version of 9558B, high gain and good   linearity.
  Length: 140 mm

9558B   Series

51 mm

red/infra-red trialkali

1 x 10⁶

-80 to +60 °C

Established high gain venetian blind type, superseded by   9202B.
  Length: 140 mm

9658B   Series

51 mm

red/infra-red trialkali

8 x 10⁵

-80 to +60 °C

Variant of 9558B, prismatic window giving enhanced red and IR   sensitivity.
  Length: 140 mm

9816B   Series

51 mm

red/infra-red trialkali

2.5 x 10⁷

-80 to +60 °C

Variant of 9817B with 14 dynodes for high gain capability.
  Length: 153 mm

9817B   Series

51 mm

red/infra-red trialkali

2.5 x 10⁶

-80 to +60 °C

12 stage fast linear focused type with good linearity.
  Length: 133 mm

9850B   Series

51 mm

red/infra-red trialkali

5 x 10³

-80 to +60 °C

6 stage fast PMT for high light level applications.
  Length: 89 mm

9863/100B   Series

51 mm

red/infra-red trialkali

3 x 10⁷

-80 to +60 °C

Variant of 9816B, 2.5 mm effective diameter, low dark count   and afterpulse.
  Length: 170 mm

9863/350B   Series

51 mm

red/infra-red trialkali

3 x 10⁷

-80 to +60 °C

Variant of 9816B, 9 mm effective diameter, low dark count and   afterpulse.
  Length: 170 mm

9879B   Series

51 mm

red/infra-red trialkali

2.5 x 10⁶

-80 to +60 °C

Variant of 9807B, thin blown window, shot blasted for enhanced   sensitivity.
  Length: 126 mm

9311KB   Series

78 mm

red/infra-red trialkali

2.5 x 10⁵

-80 to +60 °C

S20 version of 9305KB.
  Length: 113 mm

9307B   Series

90 mm

red/infra-red trialkali

6 x 10³

-80 to +60 °C

90 mm diameter variant of 9821B, S20, 6 dynodes for high light   levels.
  Length: 139.5 mm
